DXT5551P5
Document number: DS32066 Rev. 3 - 2
2 of 7
www.diodes.com
November 2010
© Diodes Incorporated
DXT5551P5
PowerDI is a registered trademark of Diodes Incorporated.
ADVAN
CE I
N
F
O
RM
ATI
O
N
A Product Line of
Diodes Incorporated
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Value Unit
Collector-Base Voltage V CBO
180 V
Collector-Emitter Voltage V
CEO
160 V
Emitter-Base Voltage V
EBO
6 V
Continuous Collector Current I C
600 mA
Thermal Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Value Unit
Power Dissipation (Note 4) P
D
2.25 W
Thermal Resistance, Junction to Ambient Air (Note 4) R θJA 55.5 °C/W
Power Dissipation (Note 5) P
D
1.28 W
Thermal Resistance, Junction to Ambient Air (Note 5) R θJA 97.4 °C/W
Power Dissipation (Note 6) P D
0.7 W
Thermal Resistance, Junction to Ambient Air (Note 6) R θJA 179 °C/W
Thermal Resistance, Junction to Collector Terminal R θJT 30 °C/W
Operating and Storage Temperature Range T
J
, T
STG
-55 to +150 °C
Notes: 4. Device mounted on 1.6mm FR-4 PCB, single sided 2 oz. copper, collector pad dimensions 50mm x 50mm.
5. Device mounted on 1.6mm FR-4 PCB, single sided 1 oz. copper, collector pad dimensions 25mm x 25mm.
6. Device mounted on 1.6mm FR-4 PCB, single sided 1 oz. copper, minimum recommended pad layout.
