MBR3100
Package Outline Dimensions
(1) Package Type: DO-214AC
3. 990(0. 157)
4.750(0.187)
2
.4
0
0
(0
.0
9
4
)
2
.8
3
0
(0
.1
1
1
)
1
.2
5
0
(0
.0
4
9
)
1
.6
5
0
(0
.0
6
5
)
4. 800(0. 189)
5. 280(0. 208)
0. 760(0. 030)
1. 520(0. 060)
1. 900(0. 075)
2. 290(0. 090)
0.080(0.003)
0. 310(0. 012)
0.150(0.006)
0.310(0.012)
Cathode line by
marking
