MBR3100
Thermal Characteristics
Characteristic Symbol Rating Unit
Thermal Resistance (Junction to Lead) (Note 7) R θ
JL
DO-214AC 20
o C/W
DO-27 5
Thermal Resistance (Junction to Ambient) (Note 7) R θ
JA
DO-214AC 70
DO-27 35
Note 7: Device mounted on heat sink, with minimum recommended pad layout per http://www.diodes.com
Electrical Characteristics
Characteristic Symbol Rating Unit Test Condition
Maximum Instantaneous Forward Voltage Drop (Note 8) V
F
(MAX)
0.85
V
I
F
= 3A, T
C
= +25

C
0.7 I
F
= 3A, T
C
= +125  C
Maximum Instantaneous Reverse Current (Note 8) I
R
(MAX)
0.5
mA
Rated DC Voltage, T C = +25

C
2.0 Rated DC Voltage, T C = +125

C
Note 8: Short duration pulse test used to minimize self-heating effect, Pulse Test: Pulse Width = 300µ s, Duty Cycle ≤ 2.0%.
