Data Sheet

HIGH VOLTAGE POWER SCHOTTKY RECTIFIER MBR10100C

Aug. 2013 Rev. 1. 7 BCD Semiconductor Manufacturing Limited

8

Mechanical Dimensions (Continued)

TO-220-3 (2) Unit: mm(inch)


3°

3

°

3°

9.800(0.386)

10.200(0.402)

3.560(0.140)
3.640(0.143)

0.700(0.028)
0.900(0.035)

1.170(0.046)
1.390(0.055)

2.540(0.100)

REF

2.540(0.100)

REF

1.200(0.047)
1.400(0.055)

0.600(0.024)

REF

4.400(0.173)
4.600(0.181)

2.200(0.087)
2.500(0.098)

0.400(0.016)
0.600(0.024)

1.620(0.064)
1.820(0.072)

1.200(0.047)
1.400(0.055)

3.000(0.118)

REF
