Data Sheet
HIGH VOLTAGE POWER SCHOTTKY RECTIFIER MBR10100C
Aug. 2013 Rev. 1. 7 BCD Semiconductor Manufacturing Limited
2
Pin Configuration
TF Package T Package
(TO-220F-3) (TO-220-3 (2))
S2 Package D Package
(TO-263-2) (TO-252-2 (1))
Figure 2. Pin Configuration of MBR10100C (Top View)
Figure 3. Internal Structure of MBR10100C
1
2
3 A2
K
A1
A1
K
A2
1
2
3
