Diodes DFLS1200Q - Manual (Page 3)

PowerDI is a registered trademark of Diodes Incorporated.
DFLS1200Q
Document number: DS37057 Rev. 1 - 2
3 of 4
www.diodes.com
March 2014
© Diodes Incorporated
DFLS1200Q
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
C
, T
O
TAL
C
A
P
A
C
IT
A
N
C
E (
pF
)
T
V , DC REVERSE VOLTAGE (V)
Fig. 3, Typical Total Capacitance vs. Reverse Voltage
R
0 5 10 15 20
0
1.2
1.4
1.6
1.8
0.8
0.6
0.4
0.2
2
1
0 25 50 75 100 125 150 175 200
I,
A
V
E
R
A
G
E F
O
R
WA
R
D
C
U
R
R
EN
T
(A
)
F(
A
V
)
T , AMBIENT TEMPERATURE (ºC)
Fig. 4, Forward Current Derating Curve
A
Note: 6
PowerDI ® 123
Dim Min Max Typ
A 3.50 3.90 3.70
B 2.60 3.00 2.80
C 1.63 1.93 1.78
D 0.93 1.00 0.98
E 0.85 1.25 1.00
H
0.15 0.25 0.20
L 0.55 0.75 0.65
L1 1.80 2.20 2.00
L2 0.95 1.25 1.10
All Dimensions in mm
Dimensions Value (in mm)
G 1.0
X1 2.2
X2 0.9
Y1 1.4
Y2 1.4
A
E
L L1
B
C E
L2
H
D
X1 G X2
Y2
Y1
