74LVCE1G06
SINGLE INVERTER BUFFER/DRIVER WITH
OPEN DRAIN OUTPUT
74LVC1GE06
Document number: DS32273 Rev. 2 - 2
6 of 13
www.diodes.com
December 2010
© Diodes Incorporated
NEW PROD
UC
T
Switching Characteristics
Over recommended free-air temperature range, CL = 15pF (see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
Vcc = 1.5 V
± 0.1V
Vcc = 1.8 V
± 0.15V
Vcc = 2.5 V
± 0.2V
Vcc = 3.3 V
± 0.3V
Vcc = 5 V
± 0.5V
Unit
Min Max Min Max Min Max Min Max Min Max
t
pd
A Y 1.5 7.8 1 4.5 0.8 3.2 0.8 3.2 0.8 2.7 ns
Operating Characteristics
T
A
= 25 ºC
Parameter
Test
Conditions
Vcc = 1.5 V Vcc = 1.8 V Vcc = 2.5 V Vcc = 3.3 V Vcc = 5 V
Unit
TYP TYP TYP TYP TYP
C
pd
Power
dissipation
capacitance
f = 10 MHz 3 3 3 4 6 pF
