74LVC32A
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Test
Conditions
V
CC
T
A
= -40°C to +85°C
T
A
= -40°C to +125°C
Unit
Min Max Min
Max
V
IH
High-Level Input
Voltage
1.65V to 1.95V
0.65 X V
CC
0.65 X V
CC
V
2.3V to 2.7V
1.7
1.6
2.7 V to 3.6V
2.0
2.0
V
IL
Low-Level Input
voltage
1.65V to 1.95V
0.35 X V
CC
0.35 X V
CC
V
2.3V to 2.7V
0.7
0.7
2.7V to 3.6V
0.8
0.8
V
OH
High-Level Output
Voltage
I
OH
= -100μA
1.65V to 3.6V
V
CC
– 0.2
V
CC
– 0.3
V
I
OH
= -4mA
1.65V 1.2
I
OH
= -8mA
2.3V 1.9
I
OH
= -12mA
2.7V 2.2 2.05
3.0V
2.3
2.1
I
OH
= -24mA
3.0V 2.2 2.0
V
OL
Low-Level Output
Voltage
I
OH
= 100μA
1.65V to 3.6V
0.2
0.3
V
I
OH
= 4mA
1.65V 0.45
0.6
I
OH
= 8mA
2.3V 0.70
0.85
I
OH
= 12mA
2.7V 0.40
0.6
3.0V
0.55
0.6
I
OH
=-24mA
3.0V 0.55
0.6
I
I
Input Current
V
I
=GND to 5.5V
3.6V
± 5
± 20
μA
I
OFF
Power Down
Leakage Current
V
I
or V
O
= 0V to 3.6V
0
10
20
μA
I
CC
Supply Current
V
I
= GND or V
CC
I
O
= 0
3.6V 10
40
μA
∆I
CC
Additional Supply
Current
One input at V
CC
–0.6V
Other at Vcc or Gnd.
2.7V to 3.6V
500
5000
μA
