Parameter Measurement Information
V
CC
Inputs
V
M
C
L
V
I
t
r
/t
f
2.0V to 5.5V V
CC
<3ns V
CC
/2 15pF or 50pF
Voltage Waveform
Pulse Duration
Voltage Waveform
Propagation Delay Times
Inverting and Non Inverting Outputs
Notes: A. Includes test lead and test apparatus capacitance.
B. All pulses are supplied at pulse repetition rate ≤ 10MHz.
C. Inputs are measured separately one transition per measurement.
D. t
PLH
and t
PHL
are the same as t
PD
Figure 1 Load Circuit and Voltage Waveforms
