Recommended Operating Conditions
(Note 5) (@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Conditions Min Max Unit
V
CC
Supply Voltage 2.0 5.5 V
V
I
Input Voltage 0 5.5 V
V
O
Output Voltage 0 V
CC
V
I
OH
High-Level Output Current
2.0V -50 mA
2.3V to 2.7V -2 μA
3.0V to 3.6V -6 mA
4.5V to 5.5V -12 mA
I
OL
Low-Level Output Current
2.0V 50 μA
2.3V to 2.7V 2 mA
3.0V to 3.6V 6 mA
4.5V to 5.5V 12 mA
Δt/ΔV
Input Transition Rise or Fall
Rate
2.3V to 2.7V 200
ns/V 3.0V to 3.6V 100
4.5V to 5.5V 20
T
A
Operating Free-Air
Temperature
-40 125 ºC
Note: 5. Unused inputs should be held at V
CC
or Ground.
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Test Conditions Vcc
T
A
= -40°C to +85°C T
A
= -40°C to +125°C
Unit
Min Max Min Max
V
IH
High-Level Input
Voltage
2.0V 1.5 1.5
V 2.3V to 2.7V V
CC
X 0.7 V
CC
X 0.7
3.0V to 3.6V V
CC
X 0.7 V
CC
X 0.7
4.5V to 5.5V V
CC
X 0.7 V
CC
X 0.7
V
IL
Low-Level Input
Voltage
2.0V 0.5 0.5
V 2.3V to 2.7V V
CC
X 0.3 V
CC
X 0.3
3.0V to 3.6V V
CC
X 0.3 V
CC
X 0.3
4.5V to 5.5V V
CC
X 0.3 V
CC
X 0.3
V
OH
High-Level
Output Voltage
I
OH
= -50μA 2.0V to 5.5V V
CC
-0.1 V
CC
-0.1
V
I
OH
= -2mA 2.3V 2.0 2.0
I
OH
= -6mA 3.0V 2.48 2.48
I
OH
= -12mA 4.5V 3.8 3.8
V
OL
Low-Level
Output Voltage
I
OL
= 50μA 2.0V to 5.5V 0.1 0.1
V
I
OL
= 2mA 2.3V 0.4 0.4
I
OL
= 6mA 3.0V 0.44 0.44
I
OL
= 12mA 4.5V 0.55 0.55
I
OFF
Power Down
Leakage Current V
I
or V
O
= 0 to 5.5V 0V 5 5 μA
I
I
Input Current V
I
=GND or 5.5V 0 to 5.5V ±1 ±1 μA
I
CC
Supply Current
V
I
= GND or V
CC
I
O
=0
5.5V 20 20 μA
