74LVC2G34
Switching Characteristics
T
A
= -40°C to +85°C, C
L
= 30 or 50pF (see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
V
CC
= 1.8V
± 0.15V
V
CC
= 2.5V
± 0.2V
V
CC
= 3.3V
± 0.3V
V
CC
= 5V
± 0.5V Unit
Min Max Min Max Min Max Min Max
t
pd
A Y 0.5 8.6 0.5 4.4 0.5 4.1 0.5 3.2 ns
T
A
= -40°C to +125°C, C
L
= 30 or 50pF (see Figure 1)
Parameter
From
(Input)
TO
(OUTPUT)
V
CC
= 1.8V
± 0.15V
V
CC
= 2.5V
± 0.2V
V
CC
= 3.3V
± 0.3V
V
CC
= 5V
± 0.5V
Unit
Min Max Min Max Min Max Min Max
t
pd
A Y 0.5 10.8 0.5 5.5 0.5 5.1 0.5 4.0 ns
Operating Characteristics
T
A
= +25°C
Parameter
Test
Conditions
V
CC
= 1.8V V
CC
= 2.5V V
CC
= 3.3V V
CC
= 5V
Unit
Typ Typ Typ Typ
C
pd
Power dissipation
capacitance
f = 10 MHz 17 19 20 21 pF
