3
Oct. 2009 Rev. 1. 7 BCD Semiconductor Manufacturing Limited
Data Sheet
MULTIPLE RS-232 DRIVERS AND RECEIVERS AZ75232
Functional Block Diagram
Figure 3. Functional Block Diagram of AZ75232
Package
Temperature
Range
Part Number Marking ID Packing
Type Lead Free Green Lead Free Green
SOIC-20 -40 to 85 o C
AZ75232M-E1 AZ75232M-G1 AZ75232M-E1 AZ75232M-G1 Tube
AZ75232MTR-E1 AZ75232MTR-G1 AZ75232M-E1 AZ75232M-G1 Tape & Reel
SSOP-20 -40 to 85 o C
AZ75232GS-E1 AZ75232GS-G1 AZ75232GS-E1 AZ75232GS-G1 Tube
AZ75232GSTR-E1 AZ75232GSTR-G1 AZ75232GS-E1 AZ75232GS-G1 Tape & Reel
TSSOP-20 -40 to 85 o C
AZ75232G-E1 AZ75232G-G1 232GE 232GG Tube
AZ75232GTR-E1 AZ75232GTR-G1 232GE 232GG Tape & Reel
Circuit Type
Package
M: SOIC-20
E1: Lead Free
G1: Green
AZ75232 -
Ordering Information
TR: Tape and Reel
Blank: Tube
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
V
SS
V
CC
GND
V
DD
RA1
RA2
RA3
DY3
RA4
DY2
DY1
RY5
DA3
RY4
DA2
DA1
RY3
RY2
RY1
RA5
GS: SSOP-20
G: TSSOP-20
BCD Semiconductor's Pb-free products, as designated with "E1" suffix in the part number, are RoHS compliant. Products with
"G1" suffix are available in green packages.
