VOLTAGE DETECTOR AZ70XX
Data Sheet
Ordering Information
Package
Temperature
Range
Detect
Voltage
Part Number Marking ID Packing
Type Lead Free Green Lead Free Green
TO-92 -40 to 85 o C
2.3V
AZ7023Z-E1 AZ7023Z-G1 AZ7023Z-E1 AZ7023Z-G1 Bulk
AZ7023ZTR-E1 AZ7023ZTR-G1 AZ7023Z-E1 AZ7023Z-G1 Ammo
2.5V
AZ7025Z-E1 AZ7025Z-G1 AZ7025Z-E1 AZ7025Z-G1 Bulk
AZ7025ZTR-E1 AZ7025ZTR-G1 AZ7025Z-E1 AZ7025Z-G1 Ammo
2.7V
AZ7027Z-E1 AZ7027Z-G1 AZ7027Z-E1 AZ7027Z-G1 Bulk
AZ7027ZTR-E1 AZ7027ZTR-G1 AZ7027Z-E1 AZ7027Z-G1 Ammo
2.9V
AZ7029Z-E1 AZ7029Z-G1 AZ7029Z-E1 AZ7029Z-G1 Bulk
AZ7029ZTR-E1 AZ7029ZTR-G1 AZ7029Z-E1 AZ7029Z-G1 Ammo
3.1V
AZ7031Z-E1 AZ7031Z-G1 AZ7031Z-E1 AZ7031Z-G1 Bulk
AZ7031ZTR-E1 AZ7031ZTR-G1 AZ7031Z-E1 AZ7031Z-G1 Ammo
3.3V
AZ7033Z-E1 AZ7033Z-G1 AZ7033Z-E1 AZ7033Z-G1 Bulk
AZ7033ZTR-E1 AZ7033ZTR-G1 AZ7033Z-E1 AZ7033Z-G1 Ammo
4.2V
AZ7042Z-E1 AZ7042Z-G1 AZ7042Z-E1 AZ7042Z-G1 Bulk
AZ7042ZTR-E1 AZ7042ZTR-G1 AZ7042Z-E1 AZ7042Z-G1 Ammo
4.5V
AZ7045Z-E1 AZ7045Z-G1 AZ7045Z-E1 AZ7045Z-G1 Bulk
AZ7045ZTR-E1 AZ7045ZTR-G1 AZ7045Z-E1 AZ7045Z-G1 Ammo
SOT-89 -40 to 85 o C
2.3V AZ7023RTR-E1 AZ7023RTR-G1 E723 G70A Tape & Reel
2.5V AZ7025RTR-E1 AZ7025RTR-G1 E725 G70G Tape & Reel
2.7V AZ7027RTR-E1 AZ7027RTR-G1 E727 G70B Tape & Reel
2.9V AZ7029RTR-E1 AZ7029RTR-G1 E729 G70C Tape & Reel
3.1V AZ7031RTR-E1 AZ7031RTR-G1 E731 G70H Tape & Reel
3.3V AZ7033RTR-E1 AZ7033RTR-G1 E733 G70D Tape & Reel
4.2V AZ7042RTR-E1 AZ7042RTR-G1 E742 G70E Tape & Reel
4.5V AZ7045RTR-E1 AZ7045RTR-G1 E745 G70F Tape & Reel
Circuit Type
Package
Z: TO-92
E1: Lead Free
AZ70 -
TR: Tape and Reel or Ammo
Blank: Bulk
R: SOT-89
Detect Voltage
23: 2.3V
27: 2.7V
29: 2.9V
33: 3.3V
42: 4.2V
45: 4.5V 25: 2.5V
31: 3.1V
G1: Green
BCD Semiconductor's Pb-free products, as designated with "E1" suffix in the part number, are RoHS compliant. Products with
"G1" suffix are available in green packages.
