3-TERMINAL POSITIVE LINEAR REGULATOR AZ78LXX
Data Sheet
5
Nov. 2012 Rev. 2. 2 BCD Semiconductor Manufacturing Limited
Parameter Symbol Value Unit
Input Voltage V
IN
20 V
Operating Junction Temperature T
J
150 o
C
Lead Temperature (Soldering, 10sec) T
LEAD
260 o C
Power Dissipation (T
A
=25 o C) P
D
TO-92 0.65
W SOT-223 0.7
SOT-89 0.65
Storage Temperature Range T
STG
-65 to 150 o C
ESD (Human Body Model) ESD 2000 V
ESD (Machine Model) ESD 200 V
N ote 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Max-
imum Ratings" for extended periods may affect device reliability.
Parameter Symbol Min Max Unit
Input Voltage
AZ78L05
V
IN
15
V
AZ78L08 18
AZ78L09 18
AZ78L12 18
Operating Junction Temperature T
J
-40 125 o
C
Recommended Operating Conditions
Absolute Maximum Ratings (Note 1)
