3-TERMINAL POSITIVE LINEAR REGULATOR AZ78LXX
Data Sheet
13
Nov. 2012 Rev. 2. 2 BCD Semiconductor Manufacturing Limited
Mechanical Dimensions
TO-92(Bulk Packing) Unit: mm(inch)
2.420(0.095)
2.660(0.105)
0.360(0.014)
0.760(0.030)
Φ 1.600(0.063)
MAX
12
.500
(0
.4
92
)
15
.500
(0
.6
10
)
1.270(0. 050)
TYP
3.
300
(0
.1
30
)
3.
700
(0
.1
46
)
4.
30
0(
0.
16
9)
4.
70
0(
0.
18
5)
1.000(0.039)
1.400(0.055)
4.400(0.173)
4.800(0.189)
3.430(0.135)
MIN
0.320(0.013)
0.510(0.020)
0.000(0.000)
0.380(0.015)
