APX321/APX358/APX324
LOW VOLTAGE, RAIL-TO-RAIL INPUT AND OUTPUT
SINGLE/DUAL/QUAD OPERATIONAL AMPLIFIERS
APX321/APX358/APX324 Rev. 13 3 of 18 FEBRUARY 2009
www.diodes.com © Diodes Incorporated
Absolute Maximum Ratings
(Note 6)
Symbol Description Rating Unit
ESD HBM
Human Body Model ESD
Protection
APX321 4000
V APX358 4000
APX324 4500
ESD MM Machine Model ESD Protection
APX321 350
V APX358 350
APX324 250
Differential Input Voltage ±Supply Voltage V
V
+
-V
-
Supply Voltage 5.5 V
Output Short Circuit to V
+
(Note 7)
Output Short Circuit to V
-
(Note 8)
T
ST
Storage Temperature -65 to 150 °C
T
J
Maximum Junction Temperature 150 °C
Operating Ratings
(Note 6)
Symbol Description Rating Unit
V
+
-V
-
Supply Voltage 2.5 to 5.5 V
T
A
Operating Ambient Temperature Range -40 to +85 °C
Notes: 6. Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for which the
device is intended to be functional, but specific performance is not guaranteed. For guaranteed specifications and the test conditions, see the
Electrical Characteristics.
