APX321/APX358/APX324
LOW VOLTAGE, RAIL-TO-RAIL INPUT AND OUTPUT
SINGLE/DUAL/QUAD OPERATIONAL AMPLIFIERS
APX321/APX358/APX324 Rev. 13
1 of 18
FEBRUARY 2009
©
Diodes Incorporated
(For V
+
=5V and V
-
=0V typical unless otherwise noted)
• Guaranteed 2.7V and 5V performance
• Crossover distortion eliminated
• Operating temperature range (-40°C to +85°C)
• Gain-bandwidth 1 MHz
• Low supply current
• APX321 110 µA Typ
• APX358 190 µA Typ
• APX324 340 µA Typ
• Rail-to-rail output swing @ 10 kΩ
• V
+
-10 mV
• V
-
+10 mV
• Input Common Mode Voltage Range (0 to V
+
-0.2V)
• Manufactured in standard CMOS process
• SOT353, SOT25, MSOP-8L, SOP-8L and TSSOP-14L:
Available in “Green” Molding Compound (No Br, Sb)
• Lead-free Finish / RoHS Compliant (Note 4)
The APX321/APX358/APX324 are low voltage (2.5V to 5.5V)
single, dual and quad operational amplifiers. The
APX321/APX358/APX324 are designed to effectively reduce cost
and space at low voltage levels. These devices have the
capability of rail-to-rail output swing and input common-mode
voltage range. They can also achieve an efficient speed-to-power
ratio, utilizing 1 MHz bandwidth and 1 V/µs slew rate at a low
supply current. Reducing noise pickup and increasing signal
integrity can be achieved by placing the device close to the signal
source.
The APX321 is available in 5-Pin SOT353/SOT25
packages that reduce space on pc boards and portable
electronic devices.
The APX324 is available in the TSSOP-14L
package. The APX358 is available in the MSOP-8L and SOP-8L
packages.
•
Active filters
•
General purpose low voltage applications
•
General purpose portable devices
APX3 XX XX G - 13
S : SOP8L
Part Number
Package
24 : Quad (Note 2)
Packing
Green
G : Green
58 : Dual (Note 3)
M8 : MSOP-8L
TS : TSSOP-14L
7/13 : Tape & Reel
21 : Single (Note 1)
SE : SOT353
W : SOT25
Device
Package
Code
Packaging
(Note 5)
7”/13” Tape and Reel
Quantity
Part Number Suffix
APX321WG-7
W
SOT25
3000/Tape & Reel
-7
APX321SEG-7
SE
SOT353
3000/Tape & Reel
-7
APX324TSG-13
TS
TSSOP-14L
2500/Tape & Reel
-13
APX358SG-13 S SOP-8L 2500/Tape
&
Reel
-13
APX358M8G-13 M8
MSOP-8L 2500/Tape
&
Reel
-13
Notes: 1. APX321 is only available for SOT25 and SOT353.
2. APX324 is only available for TSSOP-14L.
3. APX358 is only available for SOP-8L and MSOP-8L.
4. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
5. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
Features
General Description
Applications
Ordering Information
