Preliminary Datasheet
Octave Remote Resistor-programmable Temperature Switches AP2602
Feb. 2012 Rev. 1. 0 BCD Semiconductor Manufacturing Limited
8
Typical Performance Characteristics (Continued)
V
TMSNS1
V
TMSNS1
2V/div 2V/div
V
TMSNS2
V
TMSNS2
2V/div 2V/div
V
OT12
V
OT12
2V/div 2V/div
Time (50
µs/div) Time (10µs/div)
Figure 12. Deglitch time to OT Low (V
SEL
=V
CC
) Figure 13. Deglitch time to OT High (V
SEL
=GND)
(Conditions: V
CC
=5V, V
TMSNS1
=0.5V to 3V, (Conditions: V
CC
=5V, V
TMSNS1
=0.5V to 3V,
V
TMSNS2
=2.5V) V
TMSNS2
=2.5V, V
TRIG
=1V)
V
TMSNS1
2V/div
V
TMSNS2
2V/div
V
OT12
2V/div
Time (50
µs/div)
Figure 14. Deglitch Time to OT Low (V
SEL
=GND)
(Conditions: V
CC
=5V, V
TMSNS1
=0.5V to 3V,
V
TMSNS2
=2.5V, V
TRIG
=1V)
