Preliminary Datasheet
Octave Remote Resistor-programmable Temperature Switches AP2602
Feb. 2012 Rev. 1. 0 BCD Semiconductor Manufacturing Limited
4
Ordering Information
AP2602 -
Circuit Type G1: Green
Package
TR: Tape & Reel
FN: QFN-3X3-16
Package
Temperature
Range
Part Number Marking ID
Packing
Type
QFN-3X3-16 -40 to 125
°C
AP2602FNTR-G1 B2E Tape & Reel
BCD Semiconductor's Pb-free products, as designated with "G1" suffix in the part number, are RoHS compliant
and green.
Absolute Maximum Ratings (Note 2)
Parameter Symbol Value Unit
Supply Voltage V
CC
-0.3 to 6 V
OTXY Voltage V
OT
-0.3 to 6 V
TMSNSX, VTRIG Voltage
V
TMSNSX,
V
TRIG
-0.3 to V
CC
+0.3 V
SEL Voltage V
SEL
-0.3 to 6 V
Output Current (All Pins) 20 mA
Input Current (All Pins) 20 mA
Operating Junction Temperature T
J
150
°C
Storage Temperature Range T
STG
-65 to 150
°C
Lead Temperature
(Soldering, 10 seconds)
T
LEAD
260
°C
Thermal Resistance
θ
JA
QFN-3X3-16 68
°C/W
ESD (Machine Model) 200 V
ESD (Human Body Model) 2000 V
Note 2: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
