AH1883
MICROPOWER, ULTRA-SENSITIVE HALL EFFECT SWITCH
AH1883
Document number: DS31296 Rev. 6 - 2
3 of 10
www.diodes.com
September 2011
© Diodes Incorporated
Absolute Maximum Ratings (T
A
= 25
°C, Note 1)
Symbol Characteristics Values Unit
Vdd Supply voltage 5 V
B Magnetic flux density Unlimited
T
S
Storage Temperature Range -65 to +150
°C
P
D
Package Power Dissipation 230 mW
T
J
Maximum Junction Temperature 150
°C
Notes: 1. Stresses greater than the 'Absolute Maximum Ratings' specified above, may cause permanent damage to the device. These are stress ratings only;
functional operation of the device at these or any other conditions exceeding those indicated in this specification is not implied. Device reliability
may be affected by exposure to absolute maximum rating conditions for extended periods of time
Recommended Operating Conditions (T
A
= 25
°C)
Symbol Parameter Conditions Rating Unit
Vdd Supply Voltage Operating 1.65 to 3.3 V
T
A
Operating Temperature Range Operating -40 to +85
°C
Electrical Characteristics (T
A
= 25
°C, Vdd = 1.8V, unless otherwise specified)
Symbol Characteristic Conditions Min Typ. Max Unit
V
OH
Output On Voltage (High side) I
O
= -0.5mA Vdd-0.2 - - V
V
OL
Output On Voltage (Low side) I
O
= 0.5mA - - 0.2 V
Idd(en)
Supply Current
Chip enable - 2 4 mA
Idd(dis) Chip disable - 5 8 uA
Idd(avg) average supply current - 7 12 uA
Tawake Awake Time - 50 100 µs
Tperiod Period - 50 100 ms
D.C. Duty Cycle - 0.1 - %
