AH1804
MICROPOWER OMNIPOLAR HALL EFFECT SENSORSWITCH
AH1804
Document number: DS35314 Rev. 2 - 2
3 of 9
www.diodes.com
September 2011
© Diodes Incorporated
NEW PROD
UC
T
Absolute Maximum Ratings (T
A
= 25
°C, Note 2)
Symbol Characteristics Values Unit
V
DD
Supply voltage (Note 3) 5.0 V
V
DD rev
Reverse supply voltage -0.3 V
B Magnetic flux density Unlimited
Ts Storage Temperature Range -65 to +150
°C
P
D
Package Power Dissipation
DFN1216-4 230
mW
SC59 270
T
J
Maximum Junction Temperature 150
°C
Notes: 2. Stresses greater than the 'Absolute Maximum Ratings' specified above, may cause permanent damage to the device. These are stress ratings
only; functional operation of the device at these or any other conditions exceeding those indicated in this specification is not implied.
Device reliability may be affected by exposure to absolute maximum rating conditions for extended periods of time
3. The absolute maximum of 5V is a transient stress rating and is not meant as functional operating conditions. It is not recommended to operate the
device at the absolute maximum rated conditions for any period of time.
Recommended Operating Conditions (T
A
= 25
°C)
Symbol Characteristics Conditions Rating Unit
V
DD
Supply Voltage C
IN
=0.1µF (Note 4) 2.5 to 3.6 V
T
A
Operating Temperature Range Operating -40 to +85
°C
Notes: 4. Decoupling capacitor C IN = 100nF or higher must be used for full 2.5V to 3.6V supply range .
Electrical Characteristics (T
A
= 25
°C, V
DD
= 3.3V, unless otherwise specified)
Symbol Characteristics Conditions Min Typ. Max Unit
V
OL
Output Low Voltage (on) I
OUT
= 1mA
⎯ 0.1 0.2 V
V
OH
Output High Voltage (off) I
OUT
= -1mA V
DD
-0.2 V
DD
-0.1
⎯⎯ V
Idd(en)
Supply current
Chip enable
⎯ 4 ⎯ mA
Idd(dis) Chip disable
⎯ 8 ⎯ µA
Idd(avg) Average supply current,
⎯ 12 ⎯ µA
Tawake Awake Time (Note 5)
⎯ 50 100 µs
Tperiod Period (Note 5)
⎯ 50 100 ms
D.C. Duty Cycle
⎯ 0.1 ⎯ %
Notes: 5. When power is initially on, the operating V DD (2.5V to 3.6V) must be applied to be guaranteed for the output sampling.
The output state is valid after the second operating phase (typical 100ms).
