HIGH SENSITIVITY CMOS HALL-EFFECT LATCH AH921
Jul. 2011 Rev. 1. 2 BCD Semiconductor Manufacturing Limited
4
Absolute Maximum Ratings (Note 1)
Parameter Symbol Value Unit
Supply Voltage V
CC
28 V
Supply Current (Fault) I
CC
5 mA
Output current (Continuous) I
OUT
25 mA
TO-92S-3 400
Power Dissipation P
D
SOT-23-3 230
mW
Operating Temperature T
A
-50 to 150
ºC
Storage Temperature T
STG
-65 to 150
ºC
Maximum Junction Temperature T
J
(Max) 165
ºC
ESD (Human Body Model) ESD 3500 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Parameter Symbol Min Max Unit
Supply Voltage V
CC
3.5 24 V
Operating Temperature T
A
-40 125 ºC
