AH3761
HIGH SENSITIVITY HALL EFFECT LATCH
AH3761 Rev. 1
2 of 9
SEPTEMBER 2009
©
Diodes Incorporated
A H 3 7 6 1 - X G - X
Packing
P : SIP3
Package
Green
A : Ammo Box (Note 3)
B : Bulk (Note 4)
W : SC59
G : Green
7 : Tape & Reel
Device
Package
Code
Packaging
(Note 2)
Bulk
7” Tape and Reel
Ammo Box
Quantity
Part
Number
Suffix
Quantity
Part
Number
Suffix
Quantity
Part
Number
Suffix
AH3761-PG-A
P SIP3 NA
NA
NA
NA
4000/Box
-A
AH3761-PG-B P SIP3 1000 -B
NA
NA NA
NA
AH3761-WG-7 W SC59 NA NA
3000/Tape
&
Reel
-7
NA NA
Notes: 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at
2. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at
3. Ammo Box is for SIP3 Spread Lead.
4. Bulk is for SIP3 Straight Lead.
Pin Assignments
(1) SIP3
(2) SC59
1. Vdd
2. GND
3.
( Top View )
OUT
1 . Vdd
3.
GND 2.
OUT
( Top View )
Pin Name
P/I/O
Pin #
Description
Vdd
P 1
Positive Power Supply
GND
P 2
Ground
OUT
O 3
Output Pin
Ordering Information
Pin Descriptions
