2-PHASE HALF-WAVE HIGH VOLTAGE MOTOR PRE-DRIVER AM4406/4406F
Data Sheet
5
Nov. 2009 Rev. 1. 5
BCD Semiconductor Manufacturing Limited
Parameter Symbol
Value
Unit
Supply Voltage
V
CC
30
V
Output Current
I
OUT
70
mA
Power Dissipation
P
D
550 (Note 2)
mW
Storage Temperature Range
T
STG
-55 to 125
o
C
ESD (Human Body Model)
ESD
3000
V
ESD (Machine Model)
ESD
300
V
Note 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to the device.
These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated
under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Maximum Ratings" for extended periods
may affect device reliability.
Note 2: Reduced by 5.5mW/
o
C when T
A
is over 25
o
C.
Parameter
Symbol
Min
Max
Unit
Supply Voltage
V
CC
4
28
V
Hall Input Voltage (+) (Note 3)
V
HS
(+)
1.0
V
CC
-0.5
V
Hall Input Voltage (-) (Note 3)
V
HS
(-)
1.0
V
CC
-0.5
V
Operating Temperature
T
A
-40
95
o
C
Recommended Operating Conditions
Absolute Maximum Ratings (Note 1)
Note 3: Hall input voltage range includes the amplitude of signal.
