Absolute Maximum Ratings
(Note 6) (@T
A
Symbol
= +25°C, unless otherwise specified.)
Parameter
Rating
Unit
V
Supply Voltage
CC
18
V
I
Output Current
OUT
1.0
A
V
Output Voltage
OUT
18
V
I
HB Output Current
HB
10
mA
V
VPWM Input Voltage
PWM
6
V
V
RD Output Voltage
RD
18
V
V
FG Output Voltage
FG
18
V
I
RD Output Current
RD
10
mA
I
FG Output Current
FG
10
mA
P
D
Power Dissipation (Note 7)
SSOP-16
0.8
W
HTSSOP-14
1.1
T
Storage Temperature Range
STG
-55 to +150
°C
ESD
ESD (Human Body Model)
2000
V
ESD
ESD (Machine Model)
250
V
Notes:
6. Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only,
and functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not
implied. Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability
7. T
A
= +25°C, no external heatsink.
Recommended Operating Conditions
Symbol
Parameter
Conditions
Min
Typ
Max
Unit
V
Supply Voltage
CC
Operating
3.5
12
16
V
V
Hall Input Voltage + (Note 8)
IN+
—
0.2
—
3
V
V
IN-
Hall Input Voltage - (Note 8)
—
0.2
—
3
V
T
Ambient Temperature
A
—
-30
—
+90
°C
Note:
8. Hall input voltage range includes the amplitude of signal.
