Package Outline Dimensions
(cont.) (All dimensions in mm(inch).)
(2) Package Type: HTSSO-14
6. 350(0. 250)
6. 550(0. 258)
1. 470(0. 058)
1. 570(0. 062)
1. 450(0. 057)
1. 550(0. 061)
0. 750(0. 030)
0. 850(0. 033)
0. 650(0. 026)
BSC
1. 300(0. 051)
BSC
6. 200(0. 244)
6. 600(0. 260)
0. 340(0. 013)
0. 540(0. 021)
1. 200(0. 047)
MAX
0. 050(0. 002)
0. 200(0. 008)
0. 900(0. 035)
1. 050(0. 041)
4. 300(0. 169)
4. 500(0. 177)
SEE
DETAIL A
0. 250(0. 010)
BSC
R0. 090(0. 004)
MIN
R0. 090(0. 004)
MIN
0. 200(0. 008)
MIN
10
14
0. 450(0. 018)
0. 750(0. 030)
1. 000(0. 039)
REF
0
8
DETAIL A
°
°
°
°
Note: Eject hole, oriented hole and mold mark is optional.
0.200(0.008) or 1.480(0.058)
0.280(0.011) or 1.610(0.063)
0.100(0.004)
0.150(0.006)
0.100(0.004)
0.190(0.007)
0.200(0.008) or 1.470(0.058)
0.240(0.009) or 1.570(0.062)
BASE METAL
Φ
Φ
