SINGLE PHASE FULL WAVE DIRECT PWM MOTOR DRIVER AM4961
HIN- HIN+ COSC (Note 1) CT OUT1 OUT2 FG RD Mode
H L
H
L
H L L
L
Rotation (Drive)
L H L H OFF
H L
L
OFF L L
Rotation (Recirculate)
L H L OFF OFF
H L
H
H
H OFF L
OFF Lock Protection
L H OFF H OFF
H L
L
OFF OFF L
L H OFF OFF OFF
Truth Table
Note 1: V
OSC
(H)
>
V
PWM
, V
OSC
(L)
<
V
PWM
.
Package
Temperature
Range
Part Number Marking ID
Packing
Type
Lead Free Green Lead Free Green
SSOP-16
-30 to 90 o C
AM4961GS-E1 AM4961GS-G1 AM4961GS AM4961GS-G1 Tube
AM4961GSTR-E1 AM4961GSTR-G1 AM4961GS AM4961GS-G1 Tape & Reel
HTSSOP-14
AM4961GH-E1 AM4961GH-G1 AM4961GH AM4961GH-G1 Tube
AM4961GHTR-E1 AM4961GHTR-G1 AM4961GH AM4961GH-G1 Tape & Reel
Circuit Type
Package
GS: SSOP-16
E1: Lead Free
AM4961 -
TR: Tape and Reel
Blank: Tube
Ordering Information
GH: HTSSOP-14
G1: Green
BCD Semiconductor's Pb-free products, as designated with "E1" suffix in the part number, are RoHS compliant. Products with
"G1" suffix are available in green packages.
