Data sheet, Pin description – Diodes AM4961 User Manual
Page 3

Data Sheet
3
May. 2011 Rev. 2. 4
BCD Semiconductor Manufacturing Limited
SINGLE PHASE FULL WAVE DIRECT PWM MOTOR DRIVER AM4961
Pin Number
Pin Name
Function
HTSSOP-14
SSOP-16
1
1
OUT2
Driver output 2
2
NC
No connection
2
3
VCC
Power supply
3
4
VMIN
Minimum duty setting
4
5
VPWM
Adjustable Input
5
6
COSC
Oscillator capacitor
6
7
FG
Rotation speed indicator
7
8
RD
Rotation/lock state indicator
8
9
HIN+
Hall sensor input +
9
10
HB
Hall sensor bias regulator
10
11
HIN-
Hall sensor input -
11
12
VREF
Reference voltage regulator
12
13
CT
Lock and rotation setting capacitor terminal
13
14
GND
Ground for control circuit
14
15
OUT1
Driver output 1
16
PGND
Power ground
Pin Description
