Data Sheet
Single Phase Full-wave Motor Driver for Silent Fan Motor AM9789
Oct. 2012 Rev. 1. 1 BCD Semiconductor Manufacturing Limited
5
Absolute Maximum Ratings (T
A
=25
°C, Note 1)
Parameter Symbol Value Unit
Supply Voltage V
CC
10 V
Output Current I
OUT
1 A
Output Voltage V
OUT
10 V
HB Output Current I
HB
10 mA
FG Output Voltage V
FG
10 V
FG Output Sink Current I
FG
10 mA
Operation Temperature T
OP
-40 to 125
°C
Storage Temperature Range T
STG
-55 to 150
°C
Lead Temperature (Soldering 10s) T
LEAD
260
°C
Thermal Resistance (Junction to
Ambient)
θ
JA
MSOP-8 205
°C/W
MSOP-10 195
DFN-3x3-8 71
DFN-3x3-10 71
Thermal Resistance (Junction to Case)
θ
JC
MSOP-8 48
°C/W
MSOP-10 46
DFN-3x3-8 48
DFN-3x3-10 48
Power Dissipation P
D
MSOP-8 585
mW
MSOP-10 585
DFN-3x3-8 1760
DFN-3x3-10 1760
ESD (Human Body Model) 4000 V
ESD (Machine Model) 400 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions (T
A
=25
°C)
Parameter Symbol Min Max Unit
Supply Voltage V
CC
2 6 V
Hall Input Voltage Range V
HB
0.4 V
CC
-1.1 V
Operating Ambient Temperature T
A
-40 105
°C
