Data Sheet
Single Phase Full-wave Motor Driver for Silent Fan Motor AM9789
Oct. 2012 Rev. 1. 1 BCD Semiconductor Manufacturing Limited
16
Mechanical Dimensions (Continued)
DFN-3×3-8 Unit: mm(inch)
2.900(0. 114)
3.100(0. 122)
2.900(0. 114)
3.100(0. 122)
2.200(0. 087)
2. 400( 0. 094)
1. 400(0. 055)
1. 600(0. 063)
N8 N5
N4 N1
0.375(0. 015)
0.575(0. 023)
0.180(0. 007)
0.300(0. 012)
0.153(0. 006)
0.253(0. 010)
0.000(0. 000)
0.050(0. 002)
0.700(0. 028)
0.800(0. 031)
PIN #1 IDENTIFICATION
See DETAIL A
BSC
0.650(0.026)
Pin 1 Mark
1 2
DETAIL A
1 2 1 2
Pin 1 options
