AH266
Magnetic Characteristics
A grade
(1mT = 10 Gauss)
Symbol Characteristic Min Typ. Max Unit
Bop Operation Point 10 — 70 Gauss
Brp Release Point -70 — -10 Gauss
Bhy Hysteresis — 80 — Gauss
B grade
Symbol Characteristic Min Typ. Max Unit
Bop Operation Point — — 100 Gauss
Brp Release Point -100 — — Gauss
Bhy Hysteresis — 80 — Gauss
O
u
tp
ut
Vo
ltag
e
in
V
o
lts
Ou
tp
u
t Vo
ltag
e
in
V
olts
0 0
Magnetic Flux Density in Gauss Magnetic Flux Density in Gauss
DO DOB
Bop Bop Brp Brp
B hy Turn on Turn off B hy Turn off Turn on
V
SAT
V
SAT
Operation Characteristics
Marking Side
S
B
hy
V
SAT
V
CC
V
d
B
rp
B
op 0 S
N
(Magnetic Flux Density )
DO
High
Low
(SIP-4L)
N
(Output Voltage)
