Data Sheet
Boost Controller for WLED Driver in Medium-sized LCD Panel AP3041
Oct. 2012 Rev. 1. 2 BCD Semiconductor Manufacturing Limited
5
Ordering Information
AP3041 -
Circuit Type G1: Green
Package
M: SOIC-16
Package
Temperature
Range
Part Number Marking ID
Packing
Type
SOIC-16 -40 to 85 °C
AP3041M-G1 AP3041M-G1 Tube
AP3041MTR-G1 AP3041M-G1 Tape & Reel
BCD Semiconductor's Pb-free products, as designated with "G1" suffix in the part number, are RoHS compliant
and green.
Absolute Maximum Ratings (Note 1)
Parameter Symbol Value Unit
Input Voltage V
IN
30 V
VCC Pin Voltage V
CC
20 V
OUT Pin Voltage V
OUT
20 V
FAULT Pin Voltage
V
FAULT
20 V
FB Pin Voltage V
FB
20 V
UVLO Pin Voltage V
UVLO
7 V
CS Pin Voltage V
CS
20 V
SC Pin Voltage V
SC
7 V
FLAG Pin Voltage V
FLAG
7 V
SS/COMP Pin Voltage V
SS/COMP
7 V
RT Pin Voltage V
RT
7 V
PWM Pin Voltage V
PWM
7 V
EN Pin Voltage V
EN
30 V
OV Pin Voltage V
OV
7 V
Thermal Resistance (Junction to
Ambient, No Heat Sink, Free Air)
θ
JA
82 ºC/W
Blank: Tube
TR: Tape & Reel
