Data Sheet
Boost Controller for WLED Driver in Medium-sized LCD Panel AP3041
Oct. 2012 Rev. 1. 2 BCD Semiconductor Manufacturing Limited
13
Mechanical Dimensions
SOIC-16 Unit: mm(inch)
7°
5.800(0.228)
6.240(0.246)
0.330(0.013)
0.510(0.020)
20:1
A
1.350(0.053)
1.750(0.069)
1.250(0.049)
1.650(0.065)
7°
0°
8°
B
C
S 1.000(0.039)
0.200(0.008)
20:1
B
C
50:1
C-C
0.200(0.008)
0.250(0.010)
0.400(0.016)
1.270(0.050)
0.250(0.010)
Depth 0.200(0.008)
0.250(0.010)
0.050(0.002)
R0.200(0.008)
R0.200(0.008)
A
3.800(0.150)
4.040(0.159)
3°
8°
9.5°
8°
8°
7°
0.400(0.016)×45°
Note: Eject hole, oriented hole and mold mark is optional.
φ
