Data Sheet
4
Dec. 2012 Rev. 1. 6
BCD Semiconductor Manufacturing Limited
WHITE LED STEP-UP CONVERTER AP3031
Parameter Symbol
Value
Unit
Input Voltage
V
IN
20
V
SW Voltage
V
SW
38
V
FB Voltage
V
FB
20
V
CTRL Voltage
V
CTRL
20
V
Thermal Resistance
(Junction to Ambient, No Heat Sink)
θ
JA
SOT-23-6/TSOT-23-6
265
o
C/W
SOIC-8
120
Operating Junction Temperature
T
J
150
o
C
Storage Temperature Range
T
STG
-65 to 150
o
C
Lead Temperature (Soldering, 10sec)
T
LEAD
260
o
C
ESD (Machine Model)
600
V
ESD (Human Body Model)
4000
V
Note 1:
Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to the device.
These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated
under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Maximum Ratings" for extended periods
may affect device reliability.
Parameter
Symbol
Min
Max
Unit
Operating Temperature Range
T
OP
-40
85
o
C
Input Voltage
V
IN
2.7
16
V
CTRL Voltage
V
CTRL
16
V
Recommended Operating Conditions
Absolute Maximum Ratings (Note 1)
