AL8807
Electrical Characteristics
(@V
IN
= 12, T
A
= +25°C, unless otherwise specified.)
Symbol Parameter
Conditions
Min
Typ
Max
Unit
V
INSU
Internal Regulator Start-Up Threshold
V
IN
rising
5.9
V
V
INSH
Internal Regulator Hysteresis Threshold
V
IN
falling
100 300
mV
I
Q
Quiescent Current
Output not switching (Note 4)
350
µA
I
S
Input Supply Current
CTRL pin floating f = 250kHz
1.8
5
mA
V
TH
Set current Threshold Voltage
95
100
105
mV
V
TH-H
Set Threshold Hysteresis
±20
mV
I
SET
SET Pin Input Current
V
SET
= V
IN
-0.1
16
22
µA
R
CTRL
CTRL Pin Input Resistance
Referred to internal reference
50
k
Ω
V
REF
Internal Reference Voltage
2.5
V
R
DS(on)
On Resistance of SW MOSFET
I
SW
= 1A
0.25
0.4
Ω
t
R
SW Rise Time
V
SENSE
= 100±20mV, f
SW
= 250kHz
V
SW
= 0.1V to 12V to 0.1V, C
L
= 15pF
12 ns
t
F
SW Fall Time
20 ns
I
SW_Leakage
Switch Leakage Current
V
IN
=30V
0.5
μA
JA
Thermal Resistance Junction-to-Ambient (Note 5)
SOT25 (Note 6)
250
C/W
MSOP-8EP (Note 7)
69
JL
Thermal Resistance Junction-to-Lead (Note 8)
SOT25 (Note 6)
50
JC
Thermal Resistance Junction-to-case (Note 9)
MSOP-8EP (Note 7)
4.3
Notes:
4. AL8807 does not have a low power standby mode but current consumption is reduced when output switch is inhibited: V
SENSE
= 0V. Parameter is
tested with V
CTRL
≤ 2.5V
5. Refer to figure 35 for the device derating curve.
6. Test condition for SOT25: Device mounted on FR-4 PCB (25mm x 25mm 1oz copper, minimum recommended pad layout on top layer and thermal
vias to bottom layer ground plane. For better thermal performance, larger copper pad for heat-sink is needed.
7. Test condition for MSOP-8EP: Device mounted on FR-4 PCB (51mm x 51mm 2oz copper, minimum recommended pad layout on top layer and
thermal vias to bottom layer with maximum area ground plane. For better thermal performance, larger copper pad for heat-sink is needed
8. Dominant conduction path via Gnd pin (pin 2).
9. Dominant conduction path via exposed pad.
