AP1690
Document number: DS36469 Rev. 2 - 2
6 of 9
www.diodes.com
May 2014
© Diodes Incorporated
AP1690
A Product Line of
Diodes Incorporated
N
E
W
P
R
O
D
U
C
T
Performance Characteristics
(Cont.)
FB Input Leakage Current vs. Ambient Temperature
Ordering Information
AP1690 X XX – G1
Packing Package Product Name
TR : Tape & Reel M : SO-8 G1 : Green
RoHS/Green
Diodes IC’s Pb-free products with "G1" suffix in the part number, are RoHS compliant and green.
Package
Temperature
Range
Part Number Marking ID Packing
SO-8 -40 to +105

C AP1690MTR-G1 1690M-G1 4 000/13’’Tape & Reel
Marking Information
(Top View)
-40 -20 0 20 40 60 80 100 120
1.0
1.5
2.0
2.5
3.0
F
B
In
p
u
t
L
e
a
k
a
g
e
C
u
rre
n
t
(
 A)
Ambient Temperature ( o C)
1690
M-G1
YWWAXX
First and Second Lines: Logo and Marking ID
(See Ordering Information)
Third Line: Date Code
Y: Year
WW: Work Week of Molding
A: Assembly House Code
XX: 7
th
and 8
th
Digits of Batch No.
