Preliminary Datasheet
Low-Power Off-line PSR LED Controller AP1686
Nov. 2012 Rev. 1.1 BCD Semiconductor Manufacturing Limited
5
Electrical Characteristics
V
CC
=15V, T
A
=25°C, unless otherwise specified.
Parameter Symbol
Conditions
Min
Typ
Max
Unit
UVLO SECTION
Startup Threshold
V
TH
(ST)
13
15.5
18
V
Minimal Operating Voltage
V
OPR
(MIN)
3
3.5
4.5
V
STANDBY CURRENT SECTION
Startup Current
I
ST
V
CC
=V
TH
(ST)-1V,
Before startup
0 0.2 0.6
μA
Operating Current
I
CC
(OPR) Static
current
250
400 600
DRIVE OUTPUT SECTION
Output Current
Sink I
SINK
Apply 1V @OUT pin
200
300
500
mA
Source I
SOURCE
24
30
45
mA
CURRENT SENSE SECTION
Current Sense Threshold
Voltage
V
CS
440
500
550
mV
Equivalent Current Sense
Voltage Accuracy (Note 2)
eq
Vcs
eq
Vcs
,
,
Δ
4
%
Leading Edge Blanking
t
LEB
The minimum power
switch turn on time
300 475 720 ns
FEEDBACK INPUT SECTION
Input Resistance of FB Pin
R
FB
V
FB
=4V 1
1.6
2
M
Ω
Feedback Threshold
V
FB
3.7
3.974
4.21
V
LINE COMPENSATION SECTION
Line Compensation
Transconductance (Note 2)
g
m
1.14
1.43
1.72
μS
PROTECTION SECTION
Over Voltage Protection
V
FB
(OVP)
6.5
7.5
8.5
V
Maximum On Time of
Primary Side
tonp
(MAX)
11
18
50
μ
s
Note 2: The output current is given by
Ns
Np
Rcs
eq
Vcs
I
OUT
Ч
=
,
