Preliminary Datasheet
Low-Power Off-line PSR LED Controller AP1686
Nov. 2012 Rev. 1.1 BCD Semiconductor Manufacturing Limited
4
Ordering Information
AP1686 -
Package
Temperature
Range
Part Number Marking ID Packing Type
SOT-23-6 -40 to 85
°C
AP1686K6TR-G1 GBQ Tape & Reel
BCD Semiconductor's Pb-free products, as designated with "G1" suffix in the part number, are RoHS compliant
and green.
Absolute Maximum Ratings (Note 1)
Parameter Symbol Value Unit
Supply Voltage V
CC
-0.3 to 30 V
CS to GND Voltage -0.3 to 7 V
FB Input Voltage V
FB
-40 to 7.5 V
Source Current at OUT Pin I
SOURCE
Internally Limited A
Operating Junction Temperature T
J
150 ºC
Storage Temperature T
STG
-65 to 150 ºC
Lead Temperature (Soldering, 10
sec)
T
LEAD
300 ºC
Thermal Resistance (Junction to
Ambient)
θ
JA
200 ºC/W
ESD (Human Body Model) 2000 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
G1: Green
TR: Tape & Reel Package
K6: SOT-23-6
Circuit Type
