AZ1117C
Document number: DS36676 Rev. 2 - 2
6 of 21
www.diodes.com
January 2014
© Diodes Incorporated
AZ1117C
A Product Line of
Diodes Incorporated
Electrical Characteristics AZ1117C-1.8
(cont.)
(Operating Conditions: V
IN
≤ 10V, I
OUT
= 10mA, T
J
= +25°C, unless otherwise specified. (P ≤ maximum power dissipation). Limits appearing in
Boldface type apply over the entire junction temperature range for operation, -20°C to +125°C.)
Symbol Parameter Conditions Min Typ Max Unit
V
OUT
Output Voltage 1.5V ≤ V
IN
-V
OUT
≤ 10V
1.782 1.8 1.818
V
1.764 1.8 1.836
V
RLINE
Line Regulation 1.5V ≤ V
IN
-V
OUT
≤ 10V
— 0.5 6
mV
— — 10
V
RLOAD
Load Regulation — — 2 15 mV
V
DROP
Dropout Voltage
∆V
OUT
= 1%,
I
OUT
= 0.8A
SOT223 — 1.2 1.3 V
TO2522 (3)/
TO2522 (4)/
TO2522 (5)
— 1.3 1.4 V
I
LIMIT
Current Limit — 1 1.35 — A
I
Q
Quiescent Current I
OUT
= 0 — 4 6 mA
PSRR Ripple Rejection
f = 120Hz, C
OUT
= 22µF
(V
IN
-V
OUT
) = 3V, I
OUT
= 300mA
— 70 — dB
— Temperature Stability – — 0.5 — %
— RMS Output Noise (% of V
OUT
) T
A
= +25°C, 10Hz ≤ f ≤ 10KHz — 0.003 — %
— Thermal Shutdown Junction Temperature — +160 — °C
— Thermal Shutdown Hysteresis – — +16 — °C
θ
JC
Thermal Resistance
(Junction to Case)
SOT89-3L — 30 —
°C/W SOT223 — 15 —
TO2522(3) /TO2522(4) /TO2522(5) — 10 —
Electrical Characteristics AZ1117C-2.5
(cont.)
(Operating Conditions: V
IN
≤ 10V, I
OUT
= 10mA, T
J
= +25°C, unless otherwise specified. (P ≤ maximum power dissipation). Limits appearing in
Boldface type apply over the entire junction temperature range for operation, -20°C to +125°C.)
Symbol Parameter Conditions Min Typ Max Unit
V
OUT
Output Voltage 1.5V ≤ V
IN
-V
OUT
≤ 10V
2.475 2.5 2.525
V
2.455 2.5 2.545
V
RLINE
Line Regulation 1.5V ≤ V
IN
-V
OUT
≤ 10V
— 0.5 6
mV
— — 10
V
RLOAD
Load Regulation — — 2 15 mV
V
DROP
Dropout Voltage
∆V
OUT
= 1%,
I
OUT
= 0.8A
— — 1.2 1.3 V
TO2522 (3)/
TO2522 (4)/
TO2522 (5)
— 1.3 1.4 V
I
LIMIT
Current Limit — 1 1.35 — A
I
Q
Quiescent Current I
OUT
= 0 — 4 6 mA
PSRR Ripple Rejection
f = 120Hz, C
OUT
= 22µF
(V
IN
-V
OUT
) = 3V, I
OUT
= 300mA
— 70 — dB
— Temperature Stability — — 0.5 — %
— RMS Output Noise (% of V
OUT
) T
A
= +25°C, 10Hz ≤ f ≤ 10KHz — 0.003 — %
— Thermal Shutdown Junction Temperature — +160 — °C
— Thermal Shutdown Hysteresis — — +16 — °C
θ
JC
Thermal Resistance
(Junction to Case)
SOT89-3L — 30 —
°C/W SOT-223 — 15 —
TO2522(3) /TO2522(4) /TO2522(5) — 10 —
