AP7361
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter
Ratings
Unit
ESD HBM
Human Body Model ESD Protection
> 2
KV
ESD MM
Machine Model ESD Protection (Note 5)
> 200
V
V
IN
Input Voltage
6.5 V
OUT, ADJ, EN Voltage
V
IN
+0.3
V
T
J
Operating Junction Temperature Range
-40 to +150
°C
T
ST
Storage Temperature Range
-65 to +150
°C
P
D
Power Dissipation (Note 4)
Internally limited by maximum junction
temperature of +150°C
P
D
Power Dissipation (Note 4)
U-DFN3030-8 1700
mW
TO252 1250
SOT223 1100
SOT89-5 800
SO-8EP 1190
Notes:
4. Ratings apply to ambient temperature at +25°C.
5. ESD MM rating at 150V for EN pin in SOT89-5L package.
Stresses greater than the 'Absolute Maximum Ratings' specified above, may cause permanent damage to the device. These are stress ratings only;
functional operation of the device at these or any other conditions exceeding those indicated in this specification is not implied. Device reliability may be
affected by exposure to absolute maximum rating conditions for extended periods of time.
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Symbol Parameter Min
Max
Unit
V
IN
Input Voltage
2.2
6.0
V
I
OUT
Output Current (Note 6)
0
1.0
A
T
A
Operating Ambient Temperature
-40
+85
C
Note:
6. The device maintains a stable, regulated output voltage without a load current. When the output current is large, attention should be given to the
limitation of the package power dissipation.
