AP133
300mA, LOW QUIESCENT CURRENT, FAST TRANSIENT
LOW DROPOUT LINEAR REGULATOR
AP133 Rev. 5 7 of 15 FEBRUARY 2009
www.diodes.com © Diodes Incorporated
Typical Performance Characteristics
(Continued)
ADJ Pin Voltage vs. Input Voltage
0.7990
0.7995
0.8000
0.8005
0.8010
0.8015
0.8020
2.0 3.0 4.0 5.0 6.0
Input Voltage (V)
ADJ Pin Voltage (V)
Dropout Voltage vs. I
OUT
0
50
100
150
200
250
300
350
400
450
0.0 50.0 100.0 150.0 200.0 250.0 300.0
I
OUT
(mA)
D
rop
out
V
olta
g
e
(
m
V
)
25°C
90°C
-45°C
Current Limit Protection
Time (50us/div)
Current Limit vs. Temperature
500
550
600
650
700
750
800
-50 -30 -10 10 30 50 70 90
Temperature (°C)
C
urre
nt Lim
it
(
m
A)
Vin=3.3V, Vout=1.2V
Vin=5.0V, Vout=3.3V
Short Circuit Protection
Time (1ms/div)
Short Circuit Protection
Time (2ms/div)
V
OUT
=3.3V
