AP133
300mA, LOW QUIESCENT CURRENT, FAST TRANSIENT
LOW DROPOUT LINEAR REGULATOR
AP133 Rev. 6 4 of 15 FEBRUARY 2009
www.diodes.com © Diodes Incorporated
Absolute Maximum Ratings
Symbol Parameter Ratings Unit
V
IN
Input Voltage 7 V
OUT, ADJ, EN Voltage V
IN
+ 0.3 V
Continuous Load Current Internal Limited
T
OP
Operating Junction Temperature Range -40 ~ 125 °C
T
ST
Storage Temperature Range -65 ~150 °C
P
D
Power Dissipation (Note 3)
SOT25 740 mW
DFN2020-6 900
mW
T
J
Maximum Junction Temperature 150 °C
Recommended Operating Conditions
Symbol Parameter Min Max Unit
V
IN
Input voltage (Note 4) 2 6 V
I
OUT
Output Current 0 300 mA
T
A
Operating Ambient Temperature -40 85
°C
Notes: 3. Ratings apply to ambient temperature at 25°C
4. At V
IN
< 2.2V and T
A
< -20 °C, the output current capability may be reduced.
