AP2182A/ AP2192A
Document number: DS32193 Rev. 3 - 2
6 of 16
www.diodes.com
March 2013
© Diodes Incorporated
AP2182A/ AP2192A
Typical Performance Characteristics
(cont.)
Turn-On Delay and Rise Time
500us/div
Turn-Off Delay and Fall Time
500us/div
Short Circuit Current,
Device Enabled Into Short
500us/div
Inrush Current with
Different Load Capacitance
500us/div
1 Ω Load Connected to Enabled Device
2ms/div
0.6 Ω Load Connected to Enabled Device
2ms/div
Vout
2V/div
EN
5V/div
CL=100

F
TA= +25°C
RL=5Ω
Vout
2V/div
EN
5V/div
CL=100

F
TA= +25°C
RL=5Ω
Iin
500mA/div
Iin
500mA/div
Iout
500mA/div
EN
5V/div
VIN=5V
TA= +25°C
CL=1

F
Iin
500mA/div
EN
5V/div
VIN=5V
TA= +25°C
RL=3Ω
C
L
=470

F C
L
=220

F
C
L
=100

F
VIN=5V
TA= +25°C
CL=1

F
FLG
2V/div
Iout
1A/div
VIN=5V
TA= +25°C
CL=1

F
FLG
2V/div
Iout
1A/div
