AP2182A/ AP2192A
Document number: DS32193 Rev. 3 - 2
5 of 16
www.diodes.com
March 2013
© Diodes Incorporated
AP2182A/ AP2192A
Typical Performance Characteristics
V
EN
90%
V
OUT
T
D(ON)
10%
T
D(OFF)
50% 50%
T
R
10%
90%
T
F
V
EN
90%
V
OUT
T
D(ON)
10%
T
D(OFF)
50% 50%
T
R
10%
90%
T
F
Figure 1. Voltage Waveforms: AP2182A (left), AP2192A (right)
Figure 2. Response Time to Short Circuit Waveform
All Enable Plots are for AP2182A Active Low
Turn-On Delay and Rise Time
500µs/div
Turn-Off Delay and Fall Time
500µs/div
Vout
2V/div
EN
5V/div
CL=1

F
TA= +25°C
RL=5Ω
Vout
2V/div
EN
5V/div
CL=1

F
TA= +25°C
RL=5Ω
Iin
500mA/div
Iin
500mA/div
