AP2142A/ AP2152A
Document number: DS32191 Rev. 3 - 2
7 of 16
www.diodes.com
March 2013
© Diodes Incorporated
AP2142A/ AP2152A
Typical Performance Characteristics
(cont.)
Short Circuit with Blanking Time and Recovery Power On
20ms/div 1ms/div
Power Off Device Enabled
10ms/div 1ms/div
Device Disabled UVLO Increasing
1ms/div 1ms/div
Iout
1A/div
Vout
5V/div
VIN=5V
TA= +25°C
CL=1

F
FLG
5V/div
TA= +25°C
CL=1

F
RL=10Ω
Vout
5V/div
FLG
5V/div
Iout
200mA/div
Vin
5V/div
TA= +25°C
CL=1

F
RL=10Ω
FLG
5V/div
Iout
200mA/div
EN
5V/div
Vout
5V/div
TA= +25°C
CL=1

F
RL=10Ω
Vin
2V/div
Iout
200mA/div
Vout
5V/div
TA= +25°C
CL=1

F
RL=10Ω
Vout
5V/div
FLG
5V/div
Iout
200mA/div
Vin
5V/div
TA= +25°C
CL=1

F
RL=10Ω
Vout
5V/div
FLG
5V/div
Iout
200mA/div
EN
5V/div
