Performance Characteristics
(Cont.)
Over Voltage Protection (V
IN
= 12V, V
OUT
= 1.5V)
V
OUT
1V/div
V
UGATE
20V/div
Time 20ms/div
V
LGATE
10V/div
V
COMP
1V/div
