AP3585A/B/C
Document number: DS36819 Rev. 1 - 2
7 of 18
www.diodes.com
January 2014
© Diodes Incorporated
AP3585A/B/C
A Product Line of
Diodes Incorporated
NEW PROD
UC
T
Performance Characteristics
(Cont.)
Power-on Waveform (V
IN
= 12V, V
OUT
= 1.5V, I
OUT
= 0A) Enable-on Waveform (V
IN
= 12V, V
OUT
= 1.5V, I
OUT
= 0A)
Load Transient Response Load Transient Response
(V
IN
= 12V, V
OUT
= 1.5V, I
OUT
= 0A to 10A) (V
IN
= 12V, V
OUT
= 1.5V, I
OUT
= 0A to 20A)
Over Current Protection (V
IN
= 12V, V
OUT
= 1.5V) Under Voltage Protection (V
IN
= 12V, V
OUT
= 1.5V)
V
IN
10V/div
V
OUT
1V/div
Time 4ms/div
V
OUT
1V/div
V
COMP
0.5V/div
V
LGATE
5V/div
V
COMP
0.5V/div
V
UGATE
20V/div
V
LGATE
10V/div
Time 4ms/div
V
OUT_AC
50mV/div
I
OUT
5A/div
Time 400µs/div
V
OUT_AC
50mV/div
I
OUT
10A/div
Time 400µs/div
V
OUT
1V/div
V
OUT
1V/div
V
PHASE
10V/div
V
COMP
1V/div
I
OUT
50A/div
Time 10ms/div
V
UGATE
20V/div
V
LGATE
10V/div
V
COMP
1V/div
Time 20ms/div
