AP3585A/B/C

Document number: DS36819 Rev.

1 - 2

16 of 18

www.diodes.com

January 2014

© Diodes Incorporated

AP3585A/B/C

A Product Line of

Diodes Incorporated

NEW PROD

UC

T

Suggested Pad Layout

(1) Package Type: SO-8


Dimensions

Z

(mm)/(inch)

G

(mm)/(inch)

X

(mm)/(inch)

Y

(mm)/(inch)

E

(mm)/(inch)

Value 6.900/0.272 3.900/0.154 0.650/0.026 1.500/0.059 1.270/0.050
