Electrical Characteristics
(Cont.) (@V
CC
=5V, T
A
=+25

C, unless otherwise specified.)
Parameters Conditions Min Typ Max Unit
Output Current
Source V
CC
= 15V, V
ID
=1V  V
O
= 2V 20 40 –
mA
Sink V
CC
= 15V, V
ID
= -1V  V
O
= 2V 8 20 –
Output Voltage Swing (High) V CC = 30V, R L = 10k Ω 
V ID = 1V 27 28 – V
Output Voltage Swing (Low) V
CC
= 30V, R
L
= 10k Ω 
V
ID
= -1V
– 17 100 mV
Slew Rate
V
CC
= 18V, R
L
= 2k Ω  A
V
= 1,
V
IN
= 0.5V to 2V, C
L
= 100pF
0.2 0.5 – V/ μs
Unity Gain Bandwidth V
CC
= 30V, R
L
= 2k Ω 
C
L
= 100pF 0.7 1.0 – MHz
Op Amp 2 Section (V
CC
= 5V, V
O
=1.4V, T
A
=+25°C, unless otherwise noted.) 
Input Offset Voltage (Note 6)
T A = +25°C, V CC = 5V or 20V – 0.5 2
mV
T
A
= -40°C to +105°C, V
CC
= 5V or 20V – – 3
Input Offset Voltage Temperature Drift T
A
= -40°C to +105°C – 7 – μV/°C
Input Offset Current T
A
= +25°C – 2 30 nA
Input Bias Current T
A
= +25°C – 20 150 nA
Input Voltage Range V
CC
= 0 to 36V 0 – V
CC
-1.5 V
Common Mode Rejection Ratio T
A
= +25°C, V
CM
= 0 to 3.5V 70 85 – dB
Large Signal Voltage Gain V
CC
= 15V, R
L
= 2k Ω 
V
O
= 1.4V to 11.4V 85 100 – dB
Power Supply Rejection Ratio V
CC
= 5V to 30V 70 90 – dB
Output Current
Source V
CC
= 15V, V
ID
= 1V

V
O
= 2V 20 40 –
mA
Sink V
CC
= 15V, V
ID
= -1V

V
O
= 2V 8 20 –
Output Voltage Swing (High) V
CC
= 30V, R
L
= 10k Ω  V
ID
= 1V 27 28 – V
Output Voltage Swing (Low) V
CC
= 30V, R
L
= 10k Ω  V
ID
= -1V – 17 100 mV
Slew Rate
V
CC
= 18V, R
L
= 2k Ω 
A
V
= 1,
V
IN
= 0.5V to 2V, C
L
= 100pF
0.2 0.5 – V/ μs
Unity Gain Bandwidth V
CC
= 30V, R
L
= 2k Ω  C
L
= 100pF 0.7 1.0 – MHz
Note 6: The full temperature feature is guaranteed by design.
