AP4310E
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(Note 4)
Symbol
Parameter
Rating
Unit
V
CC
Power Supply Voltage (VCC to GND)
40
V
V
IN
Op Amp1 and 2 Input Voltage Range (Pins 2, 5, 6)
-0.3 to V
CC
+0.3
V
V
ID
Op Amp 2 Input Differential Voltage (Pins 5, 6)
40
V
I
K
Voltage Reference Cathode Current (Pin 3)
100
mA
P
D
Power Dissipation (T
A
=+25°C)
500
mW
T
J
Operating Junction Temperature
+150
C
T
STG
Storage Temperature Range
-65 to +150
C
T
LEAD
Lead Temperature (Soldering 10sec)
+260
C
Note 4
: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
(Note 5)
Parameter
Min
Max
Unit
Supply Voltage
3
36
V
Ambient Temperature
-40
+105
C
Note 5: Qualified for SMD on the underside of a PCB by processing the PCB through a wave soldering operation.
Electrical Characteristics
(@V
CC
=5V, T
A
=+25
C, unless otherwise specified.)
Parameters
Conditions
Min
Typ
Max
Unit
Total Supply Current, excluding Current in
Voltage Reference
V
CC
=5V, no load, -40°
C≤T
A
≤+105°C
–
0.15
0.25
mA
V
CC
=30V, no load, -40°
C≤T
A
≤+105°C
–
0.20
0.30
Voltage Reference Section
Reference Voltage
I
K
=10mA
T
A
=+25°C
2.49
2.50
2.51
V
-40°
C≤T
A
≤+105°C
2.48
2.50
2.52
Reference Voltage Deviation over Full
Temperature Range
I
K
=10mA, T
A
=-40°C to +105°C
–
5
24
mV
Minimum Cathode Current for Regulation
–
–
0.01
0.05
mA
Dynamic Impedance
I
K
=1mA to 80mA, f<1kHz
–
0.2
0.5
Ω
Op Amp 1 Section (V
CC
=5V, V
O
=1.4V, T
A
=+25°C, unless otherwise noted.)
Input Offset Voltage
T
A
=+25°C
–
0.5
3
mV
T
A
=-40°C to +105°C
–
–
5
Input Offset Voltage Temperature Drift
T
A
=-40°C to +105°C
–
7
–
μV/°C
Input Bias Current (Inverting Input Only)
T
A
=+25°C
–
20
150
nA
Large Signal Voltage Gain
V
CC
=15V, R
L
=2k
Ω
V
O
=1.4V to 11.4V
85
100
–
dB
Power Supply Rejection Ratio
V
CC
=5V to 30V
70
90
–
dB
